Product Collection
Intel® Celeron® Processor G Series
Code Name
Products formerly Haswell
Vertical Segment
Desktop
Processor Number
G1840
Lithography
22 nm
CPU Specifications
Total Cores
2
Total Threads
2
Processor Base Frequency
2.80 GHz
Cache
2 MB
Bus Speed
5 GT/s
TDP
53 W
Supplemental Information
Marketing Status
Discontinued
Launch Date
Q2'14
Expected Discontinuance
07/14/2017
Servicing Status
End of Servicing Lifetime
End of Servicing Updates Date
Wednesday, June 30, 2021
Embedded Options Available
No
Datasheet
View now
Memory Specifications
Max Memory Size (dependent on memory type)
32 GB
Memory Types
DDR3-1333, DDR3L-1333 @ 1.5V
Max # of Memory Channels
2
Max Memory Bandwidth
21.3 GB/s
ECC Memory Supported ‡
Yes
Processor Graphics
Processor Graphics ‡
Intel® HD Graphics for 4th Generation Intel® Processors
Graphics Base Frequency
350 MHz
Graphics Max Dynamic Frequency
1.05 GHz
Graphics Video Max Memory
1.7 GB
Graphics Output
eDP/DP/HDMI/DVI/VGA
Max Resolution (HDMI)‡
1920x1080@60Hz
Max Resolution (DP)‡
2560x1600@60Hz
Max Resolution (eDP - Integrated Flat Panel)‡
2560x1600@60Hz
Max Resolution (VGA)‡
1920x1200@60Hz
DirectX* Support
11.1/12
OpenGL* Support
4.3
Intel® Quick Sync Video
Yes
Intel® Clear Video HD Technology
Yes
# of Displays Supported ‡
3
Expansion Options
Scalability
1S Only
PCI Express Revision
Up to 3.0
PCI Express Configurations ‡
Up to 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes
16
Package Specifications
Sockets Supported
FCLGA1150
Max CPU Configuration
1
Thermal Solution Specification
PCG 2013C
TCASE
72°C
Package Size
37.5mm x 37.5mm
Advanced Technologies
Intel® Optane™ Memory Supported ‡
No
Intel® Turbo Boost Technology ‡
No
Intel® Hyper-Threading Technology ‡
No
Intel® Transactional Synchronization Extensions
No
Intel® 64 ‡
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2
Idle States
Yes
Enhanced Intel SpeedStep® Technology
Yes
Thermal Monitoring Technologies
Yes
Intel® Virtualization Technology for Itanium (VT-i)
No
Security & Reliability
Intel® AES New Instructions
No
Secure Key
Yes
Intel® Trusted Execution Technology ‡
No
Execute Disable Bit ‡
Yes
Intel® Stable IT Platform Program (SIPP)
No
Intel® Virtualization Technology (VT-x) ‡
Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡
No
Intel® VT-x with Extended Page Tables (EPT) ‡
Yes
